ELAC Vertex Series 3 IW-VJ63

ELAC Vertex Series 3 IW-VJ63

Experience unparalleled sound quality and highest precision with the ELAC Vertex Series 3 IW-VJ63 6.5" built-in loudspeaker, equipped with the legendary JET tweeter.

Vertex III Series Overview: The Vertex III Series combines the advanced technology of ELAC's award-winning Vela speakers with the flexibility of in-wall speakers. These speakers are not only powerful, but also offer perfect harmony and a cohesive sound through the use of identical components and materials throughout the series.

JET tweeter: The iconic JET 5 tweeter is the heart of the Vertex III loudspeaker. It offers lightning-fast response and an exceptionally wide dynamic range that extends to over 50 kHz. With minimal distortion and maximum headroom, the JET 5 ensures unparalleled clarity and authenticity in the sound image. The integrated waveguide optimizes radiation for maximum efficiency and precision.

AS-XR aluminum woofer: The specially developed 6.5-inch woofer with crystal membrane and AS-XR technology delivers impressive bass reproduction. The aluminum sandwich membrane offers high rigidity with low weight and ensures detailed and structured bass reproduction. The woofer is perfectly matched to the JET tweeter and ensures seamless transfer in the frequency range.

Technical specifications:

• Type: 2-way, open at the back
• Tweeter: JET Folded Ribbon
• Woofer: 6.5-inch Crystal Aluminum Cone
• Crossover frequency: 3,000 Hz
• Frequency range: 45 to 40,000 Hz
• Sensitivity: 88 dB at 2.83 V/1 m
• Recommended amplifier power: 40 to 120 watts
• Nominal/peak power: 50/120 watts
• Nominal impedance: 4 ohms
• Finish: Black Baffle/White Grille
• Grid: metal, magnetic and paintable
• Accessories: cutting template, manual
• Dimensions (diameter): 322.3 mm x 215.3 mm
• Cutout (diameter): 295 mm x 187 mm
• Installation depth: 100 mm

Easy installation: The ELAC Vertex Series 3 IW-VJ63 speakers are easy to install and come with a practical cut-out template. The elegant design with paintable magnetic grille fits seamlessly into any room design.

Product highlights:

• High-performance JET 5 tweeter for crystal-clear sound
• Crystal membrane woofer with AS-XR technology for precise bass
• Finely tuned crossover for harmonious sound
• Modern design with paintable magnetic grid
• Easy installation with accessories

Transform your audio experience with the Vertex III 6.5" in-wall speaker and enjoy premium sound quality in your room.
